1.The fully integrated water cooling system and electric control box are on the machine when working. It is convenient to operate without separate electric control box. The integrated water cooling system adds heat dissipation function and has good heat dissipation function.
2.The machine is equipped with a manual oil filling system. In addition, there is an oil receiving box under the main shaft to prevent excess lubricating oil from dropping onto the table and polluting the processed materials.
3.The machine is equipped with a dedusting installation part and a dedusting pipe cap, which is very convenient when connecting the dedusting pipe.
4.With 3 pcs emergency stop switches.If need emergency stop the machine,press any one is ok.It can quickly avoid misoperation and protect personnel and machines.
Model |
ETA1325N |
ETA1530N |
Working Area |
1300X2500X200MM |
1500X3000X200MM |
Mechanical Structure |
Weld |
|
Transmission |
Taiwan square rails+high precision ballscrew |
|
Spindle |
3.2KW or 4.5KW |
|
Motor |
Step Motor(Optional:Servo Motor) |
|
Controller |
DSP(Optional:NCstudio) |
|
Software |
Artcam(Optional:Type3) |
